GENUINE PARTS FOR BEST PERFORMANCE |
|
Gemini Saw Manufacturers the Taurus and Apollo Series of Ring Saws |
Sunshine Offers only Genuine
Gemini Saw Blades and Replacement Parts
Be assured that you are buying only
genuine parts made in USA by Gemini Saw for their Taurus and Apollo Ring
Saws. Unlike other sources on the web, Sunshine Glassworks sells
only Genuine Gemini, no Chinese knock-offs.
We keep an extensive inventory of
replacement parts for your saw so we are able to ship to you ASAP |
|
QUICK INDEX FOR
THIS PAGE
BLADES
ACCESSORY KITS
PARTS |
HAVE A
DIFFERENT GEMINI SAW?
CLICK HERE for Taurus
II.2 Saw Blades and Parts
CLICK HERE for Apollo Saw
Blades and Parts |
|
SAW BLADES FOR
TAURUS 3 SAWS |
|
Standard Blade and Parts Kit |
TAURUS 3 BLADE AND PARTS KIT
This kit includes everything you will need for a complete overhaul
of your Taurus 3 Saw.
Includes the standard
0.072in diameter blade plus two orange groove grommet assemblies
PLUS two extra orange grommets, five blue pulleys
and a drive belt. As long as you're replacing the blade,
it is time to do the overhaul!.
=Unavailable at
this time=
$255.99 Order #03910
Standard Blade Cross Section |
|
Standard Blade |
TAURUS 3 BLADE
0.072in diameter blade, as supplied with saw when you bought it.
Recommended for glass 3/8" or less thick. Not recommended for
ceramic tile, or materials over 3/8" thick (use the Mega Blade,
below, for thicker materials)
Comes
with two orange grommets for like new performance
=Unavailable at this time=
$114.99 Order #03920
Standard Blade Cross Section
|
|
Mega Blade and Parts Kit |
TAURUS 3 MEGA BLADE AND PARTS KIT
This kit is the perfect set up for using the Mega Blade. We
recommend this kit as the Mega Blade tends to increase the wear and
tear on the saw. The kit includes the aggressive Mega Blade plus two orange groove
assemblies PLUS two extra orange grommets, five blue pulleys
and a drive belt
$259.99 Order #03911
Mega Blade Cross Section |
|
Mega Blade |
TAURUS 3 MEGA BLADE
0.072in diameter blade, has an egg-shape cross section for extra
aggressive cutting action. Very handy for cutting thicker glass or
fused glass items that are over 1/8" thick.
For best results, use with the flocked drive belt.
Comes with two orange grommets
$124.99 Order #03921
Mega Blade Cross Section |
|
Slicing Blade |
TAURUS 3 SLICING BLADE
This blade's super-thin 0.040in cross section removes the least amount of
material. Perfect for cutting murrini rod or other thick items.
Works best for cutting straight. Not so swell for curves. Use with
the Taurus Super Slicer.
For best results, use with the flocked drive belt.
Comes with two orange grommets
$124.99 #03925
Slicing Blade Cross Section
|
|
Slim Blade |
TAURUS 3 SLIM BLADE
0.062in diameter blade, is extra thin. Used for cutting tiny shapes
or where a very thin kerf is required. Note: This blade is lighter
than the standard blade and requires a lighter touch when using.
Comes with two orange grommets
$114.99 Order #03922
Slim Blade Cross Section
|
|
 |
TAURUS 3 SEPARATING BLADE
This is the standard
0.072in diameter blade, but with a trick! It has a special coupling. Used to cut
internally (like the hole in a donut) without a lead-in cut. Drill a
small hole, pass the blade through the hole and snap together. Saw
your internal cut, and separate the blade to free your piece.
Comes with two orange grommets
$114.99 Order #03923
Separating Blade Cross Section
|
|
Dichroic Blade |
TAURUS 3 DICHROIC BLADE
Gemini has taken an extra skinny 0.058in diameter blade and coated it with extra fine
diamonds. This results in a blade perfectly suited for working with
dichroic and iridized coatings. The combination of thin blade and
fine diamonds makes for a smooth edge that allows you to fire at a
lower temperature to achieve a fire polished edge.
Comes with two orange grommets
$124.99 Order #03929
Dichroic Blade Cross Section |
|
SAW BLADES AND FLOCKED BELT KITS FOR
TAURUS 3 SAWS |
|
Slicer Blade & Belt Kit |
SLICING BLADE AND FLOCKED BELT KIT
This blade's super-thin cross section removes the least amount of
material. Perfect for cutting murrini rod or other thick items.
Works best for cutting straight. Use with the Super Slicer.
Comes
with two orange grommets AND the recommended Flocked Belt -
reinforced with Kevlar to withstand the forces generated by the
slicer blade.
$172.99 Order #03934
Slicing Blade Cross Section
|
|
Speed Blade & Belt Kit |
TAURUS 3 SPEED BLADE AND FLOCKED
BELT KIT
The Speed Blade is
0.055in wide with a reverse cross section compared to the Mega
Blade. You cut against the narrow part of the blade. The thinner
cross section and aggressive diamond grit will cut glass, tile or
stone up to 3/4in thick (note, you will have to remove the blade
stabilizer to utilize the maximum 3/4" thickness)
For best results, push into the blade
when cutting.
Comes with two orange grommets and the Kevlar reinforced flocked
drive belt.
=Unavailable at
this time=
$172.99 Order #03935
Speed Blade Cross Section
(Compare to Mega Blade Cross Section, above) |
|
REPLACEMENT PARTS FOR TAURUS
3 SAWS |
|
 |
TAURUS 3 HANDY PARTS
LIST
Here's everything you need to know about your T-3 Ring Saw. List
show parts and Sunshine Catalog Numbers.
Click Here to open or
download this PDF file |
|
|
DRIVE BELT FOR RING SAWS
$48.99, Order #03820
|
|
 |
FLOCKED DRIVE BELT FOR RING SAWS
Use on Taurus 3 Saws when cutting with the Mega or Slicer Blades.
Flocked belts are fiber reinforced to stand up to the tougher
blades.
$52.99, Order #03930
|
|
 |
ORANGE GROMMETS FOR TAURUS 3
SAWS
Your saw uses TWO, sold in a pack of two.
$12.99, Order #039242
|
|
 |
ORANGE GROOVE GROMMET ASSEMBLY FOR TAURUS
3 SAWS
This is the Orange Groove Grommet with the bearing pre-installed.
Note that the blue metal hubs (as shown on photo at left) are no
longer used - your assembly will have smaller black hubs.
This part goes into positions 6 and 7 on illustration at left.
Sold individually.
Your saw uses two, one in front of the blade and one behind.
$32.59 ea, Order #03928
|
|
BLUE PULLEYS WITH BEARINGS FOR
TAURUS SAWS
Your saw uses FIVE
Blue Pulleys. FOUR have raised rails and ONE has lower rails. The
pulleys with the raised rails go in positions #1, #2, #3 and #5 on
this diagram. The pulley with lower rails is used in position #4, on
the tensioner.
See our Parts Diagram
for details on Blue Pulleys |
|
These pulleys go in positions 1,2,3 and
5 on this diagram |
BLUE PULLEYS WITH
RAISED RAILS & BEARINGS
Sold individually. Your saw uses FOUR, however it is rare that ALL
will fail. Generally only one or two are needed - the ones that are
most exposed to water.
$29.99 each, Order #03826
|
|
This pulley goes in position 4
on this
diagram |
BLUE PULLEY WITH
STANDARD RAILS & BEARINGS
Sold individually. Your saw uses ONE and it goes on the belt
tensioner in position #4
on
this diagram. Pulleys with raised rails will NOT fit in position #4.
$29.99 each, Order #03825
|
|
 |
DRIVE PULLEY
Sold individually. Your saw uses ONE.
$15.99, Order #03817
|
|
 |
T-3 HOLE REDUCER SHEET
These are the stick on hole reducers that you affix to the work
surface surrounding the blade. Sold as a sheet of 24.
$12.29, Order #03909
|
|
 |
BLADE STABILIZER FOR TAURUS 3 SAWS
This is standard equipment on saws produced the past couple years.
Earlier versions did not include this item. If you don't have one on
your saw, it will be worth the investment in longer blade life.
$28.99, Order #03926
|
|
 |
REPLACEMENT FACE SHIELD FOR TAURUS
3
.
$11.99. Order #03908
|
